Building .NET for Android on Windows

Building .NET for Android on Windows requires .NET and the msbuild command be available within the Command-Line environment. (The Developer Command Prompt that Visual Studio installs is sufficient.)

MSBuild version 15 or later is required.

Building .NET for Android

  1. Install the build dependencies.

  2. Clone the xamarin-android repo:

    git clone https://github.com/xamarin/xamarin-android.git

  3. Navigate to the xamarin-android directory

  4. (Optional) Configure the build.

  5. In a Developer Command Prompt, prepare the project:

    dotnet msbuild Xamarin.Android.sln -t:Prepare -nodeReuse:false
dotnet msbuild external\Java.Interop\Java.Interop.sln -t:Prepare -nodeReuse:false

    This will ensure that the build dependencies are installed, perform git submodule update, download NuGet dependencies, and other "preparatory" and pre-build tasks that need to be performed.

  6. Build the project:

    dotnet-local.cmd build Xamarin.Android.sln  -nodeReuse:false

  7. (For Microsoft team members only - Optional) In a Developer Command Prompt, build external proprietary git dependencies:

    dotnet-local.cmd build Xamarin.Android.sln -t:BuildExternal

    This will clone and build external proprietary components such as monodroid.

After the solution has built successfully, you can use dotnet-local.cmd to create and build Android projects.

Windows Build Notes

Currently Windows avoids building many of the macOS dependencies by downloading a zip bundle of mono-related binaries previously built on macOS. This speeds up the build and enables development on Windows, in general.

Opening Xamarin.Android.sln in Visual Studio currently tends to hold file locks on output assemblies containing MSBuild tasks. If you are only making changes to Xamarin.Android.Build.Tasks, one way to avoid this issue is to open Xamarin.Android.Build.Tasks.sln instead. But if you are working on changes outside of the build tasks, then you might prefer to work in an editor like Visual Studio Code instead and build via the command-line.

@jonathanpeppers gave a talk at Xamarin Developer Summit 2019 with a full walkthrough:

Build Xamarin.Android

Alternatives to Developer Command Prompt

The Developer Command Prompt is not explicitly required, you mostly just need a way to easily invoke MSBuild.exe.

So for example:

  • You could use: "C:\Program Files (x86)\Microsoft Visual Studio\2017\Enterprise\MSBuild\15.0\Bin\MSBuild.exe".
  • You could add MSBuild.exe to your %PATH% via Windows environment variables GUI.
  • You could setup a powershell alias to msbuild using Set-Alias.

Creating a local .NET for Android Workload

dotnet msbuild Xamarin.Android.sln -t:Prepare provisions a specific build of .NET to bin\$(Configuration)\dotnet.

Once the prepare target is complete, you can set up a local .NET for Android workload install with:

dotnet-local.cmd build Xamarin.Android.sln -t:BuildDotNet -m:1

Your local bin\$(Configuration)\lib\packs directory will be populated with a local Android "workload" in Microsoft.Android.Sdk.$(HostOS) matching your operating system.

Create a new project with dotnet-local.cmd new android:

<Project Sdk="Microsoft.NET.Sdk">
  <PropertyGroup>
    <TargetFramework>net6.0-android</TargetFramework>
    <OutputType>Exe</OutputType>
  </PropertyGroup>
</Project>

Build the project in cmd with:

> dotnet-local.cmd build foo.csproj

Or in powershell:

> dotnet-local.cmd build foo.csproj

Using the dotnet-local script will execute the dotnet provisioned in bin\$(Configuration)\dotnet and will use the locally built binaries.

See the One .NET Documentation for further details.

Creating installers

Once dotnet msbuild Xamarin.Android.sln -t:Prepare is complete, .NET for Android workload packs can be built with:

dotnet-local.cmd build Xamarin.Android.sln -t:BuildDotNet,PackDotNet -m:1

Several .nupkg files will be output in .\bin\Build$(Configuration)\nuget-unsigned.

Commercial packages will be created by this command if the dotnet-local.cmd build Xamarin.Android.sln -t:BuildExternal command was ran before building.

Building Unit Tests

Once dotnet msbuild Xamarin.Android.sln has completed, the unit tests may be built with e.g.:

dotnet-local.cmd build Xamarin.Android-Tests.sln /restore /p:Configuration=Debug /bl:bin\TestDebug\msbuild-build-tests.binlog

Note that the Debug in bin\Debug must match the Configuration which was built. If xamarin-android was built with msbuild /p:Configuration=Release ..., then this should be bin\Release, not bin\Debug.

NOTE: There is currently no equivalent to make jenkins on Windows.

Troubleshooting: Ensure you check your MSBuild version (msbuild -version) and path for the proper version of MSBuild.

Running Unit Tests

All .apk-based unit tests can be executed via

msbuild Xamarin.Android.sln /t:RunApkTests

Listing Nunit Tests

In order to get a list of the tests you can use the ListNUnitTests target

msbuild Xamarin.Android.sln /t:ListNUnitTests

This will produce a list of the tests in all of the test assemblies.

Running Specific Nunit Tests

You can run then a single (or a group) of tests using the $(TEST) msbuild property.

msbuild Xamarin.Android.sln /t:RunNunitTests /p:TEST=Xamarin.Android.Build.Tests.Aapt2Tests.Aapt2Compile

Running Individual .apk Projects

See also the tests/RunApkTests.targets and build-tools/scripts/TestApks.targets files.

All .apk-based unit test projects provide the following targets:

  • DeployTestApks: Installs the associated .apk to an Android device.
  • UndeployTestApks: Uninstalls the associated .apk from an Android device.
  • RunTestApks: Executes the unit tests contained within a .apk. This target must be executed after the DeployTestApks target.

To run an individual .apk-based test project, a package must be built, using the SignAndroidPackage target, installed, and executed.

Running .apk Projects with Include/Exclude

If an .apk-based unit test uses the NUnit [Category] custom attribute, then those tests can be explicitly included or excluded from execution by setting the $(IncludeCategories) or $(ExcludeCategories) MSBuild properties.

For example, to exclude tests that use the internet (InetAccess) category:

msbuild Xamarin.Android.sln /t:RunApkTests /p:ExcludeCategories=InetAccess

$(IncludeCategories) functions in the same fashion.

To specify multiple categories, separate each category with a : character.
